HD PRO ZERO STOP 6-24X50 SFIR FFP
Specification
- MODEL:HD PRO ZERO STOP 6-24X50 SFIR FFP
MAGNIFICATION:6X-24X
FOCAL PLANE:FIRST
FIELD VIEW():3.48°-0.82°
EYE RELIEF (MM):85-72CLICK VALUE:1/10 MRAD
TOTAL ADJUSTMENT ELEVATION:18 MRAD
TOTAL ADJUSTMENT WINDAGE:17 MRAD
OBJECTIVE DIAMETER (MM):50
OCULAR LENS DIAMETER (MM):32
RESOLUTION (“):4.87”-2.89
EXIT PUPIL DIAMETER (MM):7.8-2.1
FOCUS TYPE SF:(SIDE ADJUSTMENT)
ZERO STOP:YES
PARALLAX:100YWATER PROOF (YES/NO):YES
MAIN BODY/TUBE DIAMETER (MM):30.0
OCULAR CELL DIAMETER (MM):42.5 GAMOSA.CO.ZA
DIOPTER COMPENSATION:±2°
